SmartControl™ Meter & TouchPoint™ 39 9E-926
Operation Instructions
Table 2d: SmartControl Connectors
Item Reference
Designation
Description Wire Color Function
1
J1, pin 1 DC Common Black DC Power
J1, pin 2 DC Common Black
J1, pin 3 +24 VDC Red
J1, pin 4 +24 VDC Red
2
J2, pin 1 PRISM-Main Shield Clear insulation PRISM-Main communication
J2, pin 2 PRISM-Main Shield Clear Insulation
J2, pin 3 PRISM-Main "A" White
J2, pin 4 PRISM-Main "A" White
J2, pin 5 PRISM-Main "B" Blue
J2, pin 6 PRISM-Main "B" Blue
3
J3, pin 1 PRISM-Sub Shield Clear Insulation PRISM-Sub communication
J3, pin 2 PRISM-Sub "A" White
J3, pin 3 PRISM-Sub "B" Blue
J3, pin 4 DC Common Black
J3, pin 5 +24 VDC Red
4
J4, pin 1 DC Common-leve. Red
J4, pin 2 Input-level sensor Orange
J4, pin 3 Conductivity Black
J4, pin 4 Conductivity White
J4, pin 5 +DC voltage-level Yellow
J4, pin 6 DC Common
J4, pin 7 Temperature Sensor
5
J5, pin 1 Shutoff Solenoid Output
J5, pin 2 +24 VDC
J5, pin 3 Dump Solenoid Output
J5, pin 4 +24 VDC
J5, pin 5 Aux 3 (Front) Output
J5, pin 6 +24a VDC
J5, pin 7 Aux 4 (Rear) Output
J5, pin 8 +24a VDC
J5, pin 9 +24a VDC When using Aux 3 and Aux 4 for non pulsation add jumper
from pin 9 to 10
J5, pin 10 +24 VDC
6
J7, pin 1 DC Common
J7, pin 2 Aux 1 Input
J7, pin 3 DC Common
J7, pin 4 Aux 2 Input
J7, pin 5 QuickStart input
J7, pin 6 Aux 1 Output
J7, pin 7 +24 VDC
J7, pin 8 Aux 2 Output
J7, pin 9 +24 VDC
7
J8, pin 1 DC Common
J8, pin 2 I
2
C
communication
J8, pin 3 I
2
C
communication
J8, pin 4 DC Common
J8, pin 5 Analog Input
J8, pin 6 +5VC
8
J8, pin 1 Programming Factory Use Only
To Next Page
