Brady BBP 33 - Page 142

BBP
®
33 Sign & Label Printer User’s Manual A-9
DPL Supported Commands
Objects
Objects
Object Descriptions DPL
Draw Box
(Parameters bbbb and ssss indicate line thickness of
box and must be the same.)
1X1100000970013b0093004200020002
where:
1 =
x =
1 = Fixed Value
1 = Fixed Value
eee = Fixed Value
ffff = Row
gggg = Column
b = Box
hhhh = Box Horizontal Width
vvvv = Box Vertical Height
bbbb = Box Bottom & Top Thickness
ssss = Box Side Thickness
Draw Box
(Parameters bbbb and ssss indicate line thickness of
box and must be the same.)
1X1100000970013B093042002002
where:
1 =
x =
1 = Fixed Value
1 = Fixed Value
eee = Fixed Value
ffff = Row
gggg = Column
B = Box
hhhh = Box Horizontal Width
vvvv = Box Vertical Height
bbbb = Box Bottom & Top Thickness
ssss = Box Side Thickness
Draw Line 1X1100000970013l00930042
where:
1 =
x =
1 = Fixed Value
1 = Fixed Value
eee = Fixed Value
ffff = Row
gggg = Column
I = Line Drawing
hhhh = Horizontal Width of Line
vvvv = Vertical Height of Line
