Page 35 of 113
Figure 4-20.Process Control Card Channel Configuration
4.3.1.1 Controller
Press Controller and press Enter Key to Entering in to the Process Control Card
controller configuration. Initially it displays C1 as the first controller configuration. Use the
navigational keys to select the next Controller Channels .Use the key move to
other Controller Channels. Use key to move between the different controller Configuration
Parameters.
After completing the configuration press Back button and then press to
return to main display and save the configuration automatically.
