Input Type Range Low Rang High
PT100_JS -210°C(-346°F) 600°C(1112°F)
CT 0 Amps 90 Amps
Linear (mA or Voltage) -19999 45536
Table 4-2.Process Control Card Input Range
*B1: Range For A1SP & A2SP
Table 4-3.Range of A1SP
Table 4-4.Range of A2SP
*B2: Range For SP2
Table 4-5.Range Of SP2
If A1FN= Range of A1SP same as range of
PV1.H,PV1.L IN1
PV2.H,PV2.L IN2
P1.2 H,P1.2 L,D1.2 H ,D1.2 L IN1,IN2
If A2FN= Range of A2SP same as range of
PV1.H,PV1.L IN1
PV2.H,PV2.L IN2
P1.2 H,P1.2 L,D1.2 H ,D1.2 L IN1,IN2
If PVMD= Range of SP2 same as range of
PV1 IN1
PV2 IN2
P1-2,P2-1 IN1,IN2
