Page 52 of 113
*B11: Display Symbol and Description For AOFN
Parameter Value
Display Symbol
Description
0 PV1 Retransmit IN1 Process Value
1 PV2 Retransmit IN2 Process Value
2 P1-2 Retransmit IN1-IN2 Difference Process Value
3 P2-1 Retransmit IN2-IN1 Difference Process Value
4 SV Retransmit Set Point Value
5 MV1 Retransmit Output1 manipulation Value
6 MV2 Retransmit Output2 manipulation Value
7 DV Retransmit Deviation(PV-SV) Value
Table 4-13 Function of AOFN
*B12: Display Symbol and Description For IN1
Parameter Value
Display Symbol
Description
0 J_TC J Type Thermocouple
1 K_TC K Type Thermocouple
2 T_TC T Type Thermocouple
3 E_TC T Type Thermocouple
4 B_TC B Type Thermocouple
5 R_TC R Type Thermocouple
6 S_TC S Type Thermocouple
7 N_TC N Type Thermocouple
8 L_TC L Type Thermocouple
9 PT.DN PT 100 Ohms DIN Curve
To Next Page
