*E2: Unit determination for A2SP, A2DV and A2HY
Table 4-38.Unit Determination for A2SP,A2DV,A2HY
*E3: Unit determination for Ramp
Table 4-39.RAMP Unit
*E4: Unit determination for AOLO and AOHI
Table 4-40 .Unit Determination of AOLO & AOHI
*E5: Unit is the same as unit of PV1 ( IN1 )
*E6: Unit is the same as unit of PV2 ( IN2 )
If A2FN= Range of A2SP same as range of
DE.HI,DE.LO,DB.HI,DB.LO PV
PV1.H,PV1.L PV1
PV2.H,PV.L PV2
P1.2.H,P1.2.L,D1.2.H,D1.2.L PV1,PV2
If SPMD= Unit
MIN.R PV/Minute
HR.R PV/Hour
If AOFN= Same Unit as Unit of
PV1 PV1
PV2 PV2
P1-2,P2-1 PV1,PV2
SV PV
MV1,MV2 %
