Brainchild PR Series User Guide

Page 49 of 113
*B3: Display Symbol and Description of FUNC
Parameter Value Display Symbol Description
0 BASC Basic Function Mode
1 FULL Full Function Mode
Table 4-6.Mode Selection
*B4: Display Symbol and Description For COMM
Parameter Value Display Symbol Description
0 NONE No Communication Function
1 485 RS-485 Interface
2 232 RS-232 Interface
3 4-20 4-20mA Analog Retransmission Output
4 0-20 0-20mA Analog Retransmission Output
5 0-1V 0-1V Analog Retransmission Output
6 0-5V 0-5V Analog Retransmission Output
7 1-5V 1-5V Analog Retransmission Output
8 0-10V 0-10V Analog Retransmission Output
Table 4-7.Communication Mode
*B5: Display Symbol and Description For PROT
Parameter Value Display Symbol Description
0 RTU Modbus RTU Mode
1 ASCI Modbus ASCII Mode
