Brainchild PR Series User Guide

Page 55 of 113
Parameter Value Display Symbol Description
7 D.O1 Disable Output1
8 D.O2 Disable Output2
9 D.O1.2 Disable Output1 &Output 2
10 LOCK Lock All Parameters
Table 4-18.EIFN Function
*B17: Display Symbol and Description For OUT1
Parameter Value Display Symbol Description
0 REVR Reverse(Heating)Control Action
1 DIRT Direct(Cooling)Control Action
Table 4-19.OUT1 Action
*B18: Display Symbol and Description For O1TY & O2TY
Parameter Value Display Symbol Description
0 RELY Relay Output
1 SSRD Solid State Relay Drive Output
2 SSR Solid State Relay Output
3 4-20 4-20mA Current Module
4 0-20 0-20mA Current Module
5 0-1V 0-1V Voltage Module
6 0-5V 0-5V Voltage Module
7 1-5V 1-5V Voltage Module
8 0-10 0-10V Voltage Module
Table 4-20.OUT1 & OUT2 Type
