Brainchild PR Series - Table 4-21.OUT2 Function; Table 4-22.Display Function

Page 56 of 113
*B19: Failure transfer mode for output 1 and output 2, select BPLS ( bumpless transfer ) or
0.0 ~ 100.0 % to continue output 1 and output 2 control function as the unit fails , power starts
or manual mode starts.
*B20: Display Symbol and Description For OUT2
Parameter Value Display Symbol Description
0 NONE Output 2 no function
1 COOL PID cooling control
3 DCPS DC power supply module installed
Table 4-21.OUT2 Function
*B21: Display Symbol and Description For DISF
Parameter Value Display Symbol Description
0 PV Display PV Value
1 SV Display SV Value
Table 4-22.Display Function
*B22: Display Symbol and Description For A1FN & A2FN
Parameter Value Display Symbol Description
0 NONE No alarm function
1 TIMR Dwell timer action
2 DE.HI Deviation high alarm
3 DE.LO Deviation low alarm
