Brainchild PR Series User Guide

Page 70 of 113
*B36: Display Symbol and Description of MODE
Parameter Value Description
X.0 Perform normal mode
X.1 Enter calibration mode
X.2 Enter auto-tuning mode
X.3 Enter failure mode
X.4 Enter manual mode
X.5 Enter sleep mode
0.X Unlock condition
1.X SP1, SEL1 SEL5 are unlocked
2.X Lock all parameters except SP1
3.X All parameters are locked
Table 4-36 Mode
*C: The Parameters are preset with the default values specified in the table during production
*E: The unit PV means that the unit of parameter is the same as the unit of PV (process value ).The unit
of PV is determined by PVMD , IN1, IN2, IN1U, and IN2U.
*E1: Unit determination for A1SP, A1DV and A1HY
Table 4-37.Unit Determination for A1SP,A1DV,A1HY
If A1FN= Range of A1SP same as range of
DE.HI,DE.LO,DB.HI,DB.LO PV
PV1.H,PV1.L PV1
PV2.H,PV.L PV2
P1.2.H,P1.2.L,D1.2.H,D1.2.L PV1,PV2
