Brainchild PR Series - Table 4-14 Selection of IN1 Type; Table 4-15.Display Unit for IN1 & IN2; Table 4-16.Decimal Digit for DP1&DP2

Page 53 of 113
Parameter Value Display Symbol Description
10 PT.JS PT100 Ohms JIS Curve
11 4-20 4-20mA Linear Current Input
12 0-20 0-20mA Linear Current Input
13 0-1V 0-1V Linear Voltage Input
14 0-5V 0-5V Linear Voltage Input
15 1-5V 1-5V Linear Voltage Input
16 0-10 0-10V Linear Voltage Input
17 SPEC Special defined sensor Curve
Table 4-14 Selection of IN1 Type
*B13: Display Symbol and Description For IN1U & IN2U
Parameter Value Display Symbol Description
0 °C Degree Celsius Unit
1 °F Degree Fahrenheit Unit
2 PU Process Unit
Table 4-15.Display Unit for IN1 & IN2
*B14: Display Symbol and Description For DP1 &DP2
Parameter Value Display Symbol Description
0 NO-DP No Decimal Digit
1 1-DP One Decimal Digit
2 2-DP Two Decimal Digits
3 3-DP Three Decimal Digits
Table 4-16.Decimal Digit for DP1&DP2
