*B30: Display Symbol and Description For SPMD
Parameter Value Display Symbol Description
0 SP1.2 Use SP1 or SP2 (depends on EIFN) as set point
1 MIN.R Use minute ramp rate as set point
2 HR.R Use hour ramp rate as set point
3 PV1 Use IN1 process value as set point
4 PV2 Use IN2 process value as set point
5 PUMP Selected for pump control
Table 4-31 Set Point Mode Selection
*B31: Display Symbol and Description For SEL1-SEL5
Parameter Value Display Symbol Description
0 NONE No parameter put ahead
1 TIME Parameter TIME put ahead
2 A1.SP Parameter A1SP put ahead
3 A1.DV Parameter A1DV put ahead
4 A2.SP Parameter A2SP put ahead
5 A2.DV Parameter A2DV put ahead
6 RAMP Parameter RAMP put ahead
7 OFST Parameter OFST put ahead
8 REFC Parameter REFC put ahead
9 SHIF Parameter SHIF put ahead
10 PB1 Parameter PB1 put ahead
