Brainchild PR Series User Guide

Page 47 of 113
Parameter
Notation
Parameter Description
Range
Low
*B
Range High
*B
Default
Value
*C
Unit
*E
CJCT
Cold Junction
Compensation
Temperature
-40.0 ° C
90.0° C °C
PVR
Current Process Rate
Value
-16383 16383 PV/min
PVRH
Maximum Process Rate
Value
-16383 16383
PV/min
PVRL
Minimum Process Rate
Value
-16383 16383
PV/min
SPC
Current Target Value of
set point
-19999 45536
PV
Table 4-1.PID Parameter List
*B: The ranges of some parameters are dependent on the input types. The range of IN1 and IN2 for
various input type is shown in the following table:
Input Type Range Low Rang High
J_T/C -120°C(-184°F) 1000°C(1832°F)
K_T/C -200°C(-328°F) 1370°C(2498°F)
T_T/C -250°C(-418°F) 400°C(752°F)
E_T/C -100°C(-148°F) 900°C(1652°F)
B_T/C 0°C(32°F) 1820°C(3308°F)
R_T/C 0°C(32°F) 1767.8°C(3214°F)
S_T/C 0°C(32°F) 1767.8°C(3214°F)
N_T/C -250°C(-418°F) 1300°C(2372°F)
L_T/C -200°C(-328°F) 900°C(1652°F)
PT100_DN -210°C(-346°F) 700°C(1292°F)
