Brainchild PR Series User Guide

Page 46 of 113
Parameter
Notation
Parameter Description
Range
Low
*B
Range High
*B
Default
Value
*C
Unit
*E
PV Current Process Value
-19999 45536
PV
SV
Current set point Value
-19999 45536
PV
MV1
Current Output 1 Value
0 100.00 %
MV2
Current Output 2 Value
0 100.00 %
ALM
Contains Conditional Code
of parameters Resolution
and Current Alarm Status
0
*B33
EF7F
*B33
DV
Current Deviation (P V-
SV)Value
-12600 12600 PV
PV1 IN1 Process Value
-19999 45536
*E5
PV2
IN2 Process Value
-19999 45536
*E6
PB
Current Proportional
Band Value
0
500.0°
C
(900.0 °F)
PV
TI
Current Integral Time
Value
0 4000 Sec
TD
Current Derivative
Time Value
0 1440
Sec
EROR Current Error Code
0
*B34
40
*B34
PROG
Program
Identification Code
Contains Program
Number and Version
Number
0
*B35
15.99
*B35
MODE
Contains Lockout
Status code and
Current system mode
0
*B36
3.5
*B34
CMND Command Password
0 65535
JOB
Job Password
0 65535
