Brainchild PR Series User Guide

Page 40 of 113
Parameter
Notation
Parameter Description
Range
Low
*B
Range High
*B
Default
Value
*C
Unit
*E
PROT
COMM Protocol
Selection
0
*B5
0
*B5
0
ADDR
Address Assignment of
Digital COMM
1 255
BAUD
Baud Rate of Digital
COMM
0
*B7
9
*B7
5
DATA
Data Bit count of Digital
COMM
0
*B8
1
*B8
1
PARI
Parity Bit of Digital
COMM
0
*B9
2
*B9
0
STOP
Stop Bit Count of
Digital COMM
0
*B10
1
*B9
0
AOFN Analog Output Function
0
*B11
7
*B11
0
IN1
IN1 Sensor Type
Selection
0
*B12
17
*B12
1 (0)
IN1U IN1 Unit Selection
0
*B13
2
*B13
0 (1)
DP1
IN1 Decimal Point
Selection
0
*B14
3
*B14
1
IN1L IN1 Low Scale Value -19999 45536 0
*E5
IN1H IN1 High Scale Value -19999 45536 1000
*E5
SP1L
SP1 Low Scale Value
-19999 45536
0.0°
C
(32.0 °F)
PV
SP1H
SP1 High Scale Value
-19999 45536
1000.0°
C
(1832.0 °F)
PV
