Brainchild PR Series User Guide

Page 43 of 113
Parameter
Notation
Parameter Description
Range
Low
*B
Range High
*B
Default
Value
*C
Unit
*E
V1G
Voltage Input1 Gain
Calibration Coefficient
-199.9 199.9
CJTL
Cold Junction Low
Temperature Calibration
Coefficient
-5.0°C 40.0°C °C
CJG
Cold Junction Gain
Calibration Coefficient
-199.9 199.9
REF1
Reference Voltage1
Calibration Coefficient for
RTD1
-199.9 199.9
SR1
Serial Resistance 1
Calibration Coefficient for
RTD1
-199.9 199.9
MA1G
mA input 1 Gain Calibration
Coefficient
-199.9 199.9
REF2
Reference Voltage2
Calibration Coefficient for
RTD2
-199.9 199.9
SR2
Serial Resistance 2
Calibration Coefficient for
RTD2
-199.9 199.9
V2G
Voltage input 2 Gain
Calibration Coefficient
-199.9 199.9
MA2G
mA input 2 Gain Calibration
Coefficient
-199.9 199.9
O2L
Output 2 Low Calibration
Coefficient
0 360.0
O2H
Output 2 High
Calibration Coefficient
0 900.0
SIG1
Point 1 Signal Value of
Special Sensor
-19999 45536
