ID:
Total bitrate: Current total transport stream bitrate (including null packets
- (PID 8191))
Min total bitrate: Minimum total transport stream bitrate (including null
packets)
Max total bitrate: Maximum total transport stream bitrate (including null
packets)
Effective bitrate: Current transport stream bitrate (excluding null packets)
Min effective
bitrate:
Minimum transport stream bitrate (excluding null packets)
Max effective
bitrate:
Maximum transport stream bitrate (excluding null packets)
QAM status - QAM demod info:
Pre FEC bit error
rate:
The bit error rate before forward error correction
Post FEC bit error
rate:
The bit error rate after forward error correction
Modulation error
ratio:
The modulation error ratio (MER)
Signal to noise
ratio:
Signal to noise ratio (SNR) in dB
Front end lock: A “bulb” indicating front end lock when green, red indicates
no lock
AGC lock: A “bulb” indicating AGC lock when green, red indicates no
lock
Carrier lock: A “bulb” indicating carrier lock when green, red indicates no
lock
DVB mode lock: A “bulb” indicating DVB mode lock when green, red
indicates no lock
Level: This is a measure of the stream signal power. It is expressed
according to the level mode selection made in the Setup -
ETR view:
dBm: in decibels relative to a reference value of 1mW
dBuV: in decibels relative to a reference value of 1µ V
dBmV: in decibels relative to a reference value of 1mV
Frequency offset: The measured QAM centre frequency offset. This
measurement is available for the VB262 QAM demodulator
only.
Symbol rate offset: The measured QAM symbol rate offset. This measurement is
