6.1 Main
6.1.1 Main - Summary
The intention of this page, together with the alarm list, is to provide enough
information for the operator to immediately see if there is anything seriously wrong
with one or more input streams.
The following parameters are shown:
NTP/timesync
(Bulb): The NTP/timesync bulb indicates whether the probe clock is locked to
an external time reference signal. Green indicates that the probe is
locked to an external reference whereas grey indicates that the probe
runs in unlocked mode.
Updated: The time since the last time synchronisation update
Timezone: The timezone as selected by the operator in the Setup - Params
view
Time: The current local time (configured in Setup - Params or Setup
Time view)
