Gateway 192.168.0.1 - The default gateway is required
for the probe to connect to
devices that are not on the
same subnet
Example 2 – In-Line Management IPv4
This model is useful if there is no separate management network and both data/video
and management traffic are to use the same network. In this configuration the probe’s
management network may not even be connected. Even if the probe’s management
port is not to be used it must be configured carefully so that it does not interfere with
the data/video interface.
In this example there is only one network defined as 10.0.30.0/24.
Parameter Management
(eth2)
Data/video
(eth0)
Explanation
Enable DHCP Off Optional We cannot use DHCP for eth2
since the device is not used
IP-address 0.0.0.0 10.0.30.5 The IP-addresses of each
interface – configure eth2 to a
non-existing address
Netmask 255.255.255.2
55
255.255.255.
0
The netmasks – the subnet for
eth2 contains only one
address
Enable
management
No Yes Only run web server on the
data/video interface
Gateway - 10.0.30.1 The default gateway is
required for the probe to
connect to devices that are
not on the same subnet
Example 3 – Mixed Mode IPv4
This model is similar to the separate management model with the difference that a
web server is also run on the data/video management.
Since there is only one default gateway, in this case pointing to the management
network, clients accessing the probe via the data/video interface need to be on the
same subnet as the probe’s data/video interface.
Parameter Managemen
t (eth2)
Data/video
(eth0)
Explanation
Enable Yes Yes Run web server on both
