The Stream info field displays the following information if a complete stream other
than Ethernet is selected for relaying or recording:
Stream info
Tuning state: The tuning is either 'locked' or 'unlocked', depending on round-
robin status.
Monitoring
tuning:
The name of the stream currently selected
Stream Id: The stream ID of the selected stream
Total bitrate: The total bitrate of the selected stream (including null packets)
Effective
bitrate:
The effective bitrate of the selected stream (excluding null
packets)
Num PIDs: The number of PIDs contained within the selected stream
Num services: The number of services contained within the selected stream
The Service info field displays the following information if a service is selected for
relaying or recording:
Service info
Tuning: The tuning is either 'locked' or 'unlocked', depending on round-
robin status.
Service Id: The service ID, as signalled in PAT
Name: The stream name, as signalled in SDT
Provider: The service provider, as signalled in NIT
Type: The service encoding format
Effective
bitrate:
The service bitrate, i.e. the sum of bitrates for PIDs associated
with the service
PMT PID: The PMT PID associated with the service
PCR PID: The PCR PID associated with the service
ECM PIDs: The ECM PIDs associated with the service (if applicable)
Components: The service component PIDs and component types
When destination Relay over IP has been selected, the RDP parameters are:
RDP Ethernet
IPv4-address: The unicast address or multicast address to forward to.
Multicast addresses are in the range 224.0.0.0 –
239.255.255.255.
PROBE USERS' MANUAL VERSION 5.0
2014 © BRIDGE Technologies Co AS - Bentsebrugata 20 - N-0476 Oslo, Norway - tel: +47 22 38 51 00 -
www.bridgetech.tv
96
