2. PREPARATION
2-8.Using the air unit
2-9.Pulley rotation direction
Turn on the power switch. Confirm that the pulley ro-
tates in the direction of the arrow.
― 8 ―
BAS-705
q
t
w
r
e
y
1. Attach the air hose q to the air unit connector w
with the nut e.
2. Use air pressure at 0.49 MPa - 0.54 MPa (5 - 5.5
kgf/cm
2
).
Pull up the cap at the top of the air unit r and adjust
the pressure. After adjustment, push the cap down
to lock it.
NOTE: Every day, close the air cock t and push the
drain cock y to remove the water.
