Brother BAS-705 - X-Y Feed at Real Speed

3. PANEL OPERATION
3-2-9. X-Y feed at real speed
1. Press the MODE switch w to select AUTO mode.
2. While pressing the SELECT switch e, press the
MODE switch w.
* This will change the mode to ADJUSTMENT mode.
3. Use the ▲ and ▼SELECT switches e to move the
pointer "◆" so that "X-Y/feed" is selected, and then
press the ENTER switch t.
4. Use the ▲ and ▼SELECT switches e again to
move the pointer " ◆ " so that "X-Y real feed" is se
lected,and then press the ENTER switch t.
5. Press the ▲ SELECT switch e.
* Step operation will then be carried out at the real
sewing speed.
・The sewing pattern can be checked by operating the machine at the real sewing speed.
AUTO MODE
◆ 2nd bobbin counter
Speed
Loop length
ADJUSTMENT(/)
Loop/feed
X-Y/program
◆ X-Y/test feed
▲
― 22 ―
BAS-705
選択
SELECT
モード
MODE
確定
ENTER
リセット
RESET
電源
POWER
取り消し
CANCEL
警告
WARNING
t
e
w
REAL FEED (/ADJ/XYFD)
▲ SW =execute
X-Y/TEST FEED(ADJ)
Step feed
◆ Real feed
