7. MAINTENANCE AND INSPECTION
7-3.Draining the oil
1. Remove and empty the waste oil container q when
ever it is full.
2. After emptying the waste oil container q , screw it
back into its original position.
7-4.Cleaning the eye guard
7-5.Checking the needle
Wipe the eye guard clean with a soft cloth.
Always check that the tip of the needle is not broken
before starting sewing.
NOTE: Do not use solvents such as kerosene or thinner
to clean the eye guard.
7-6.Cleaning the machine pulley
1. Remove the rubber plug at the bottom of the motor
installation base.
2. Use an air gun to blow air in through the four holes
on the top of the machine head in order to clean the
area around the machine pulley.
― 67 ―
BAS-705
