Brother BAS-705 - Removing the Machine Head Fixing Bolt; Removing the BM Support Slide Shaft Fixing Screw

2-2.Removing the machine head fixing bolt
Remove the machine head fixing bolt q and nut.
2. PREPARATION
2-3.Removing the BM support slide shaft fixing screw
Removing the BM support slide shaft fixing screw q.
NOTE: To ensure safety when moving the machine head, tighten the BM support slide shaft fixing screw q
before moving the machine head.
― 4 ―
BAS-705
q
q
NOTE: To ensure safety when moving the head,
firsttighten the machine head fixing bolt q
before moving the machine head.
