Brother BAS-705 - Clipping Disposal Funnel Assembly (S41906-001)

11. OPTIONS
11-5. Clipping disposal funnel assembly
......
(S41906-001)
1. Cut the magic tape q into three pieces, and attach
them to the power table.
2. Set the clipping disposal funnel w, then attach as
shown in the figure.
― 86 ―
BAS-705
q
w
