1. PART NAMES AND SPECIFICATIONS
1. PART NAMES AND SPECIFICATIONS
1-1. Part names
1-2. Specifications
― 1 ―
BAS-705
First bar tacking
Second bar tacking
Cotton stand
Machine head
Operation panel
Loop unit
Power switch
Start switch
Control box
Air gun
Air unit

Max. sewing speed
Stitch length
No. of stitches
Rotary hook
Belt loop length
Belt loop width
Stitch interval
Belt loop thickness
Needle
Loop cutting
Power supply
Air pressure
Weight
Dimensions
Table height
2,100 spm
Bar tacking height 1 - 3 mm bar tacking width 7 - 22 mm
29 , 36 , 43 needle
Half rotation, double hook
48 - 78 mm (finished length)
9 - 16 mm (V cut) 9 - 20 mm (Flat cut)
40 - 70 mm
1 - 3 mm
DP×17NY#19 - 21
Flat cut, V cut (selectable)
3 phase 220V, 380V, 400V, 415V, 600VA
0.5MPa (5kg/cm
2
)
205kg (220V), 230kg (380V, 400V, 415V)
W 1100 mm L 837 mm H 1250 - 1530 mm
1000 - 1150 mm
Stitch length
0.1- 10mm
