9. ERROR CODES
― 72 ―
BAS-705
E-160
E-170
E-171
E-181
182
E-190
E-1A0
E-1A1
E-202
E-203
E-204
E-20A
E-20D
E-20E
Loop length data, bobbin thread counter
data, production counter data or sewing
speed data is corrupted.
Lower shaft module was open
when sewing started.
Lower shaft module locking error
Upper thread breaks at the first
and second bar tacking.
Loop setting error
Communication error between
main circuit board and X-Y feed
circuit board.
Communication error between
main circuit board and panel
circuit board.
Motor does not operate, or problem
with synchronizer signal.
The pattern was found to be
outside the sewing area during a
scale check.
The pattern was found to be over
the maximum pitch during a scale
check.
Error detecting X or Y home
position for X-Y feed.
Overheating of X-Y feed circuit
board
Reading or writing error of
EEPROM on in X-Y feed circuit
board
q Turn off power switch.
w Initialize the sewing data.
q Close the lower shaft.
w Press the RESET switch.
q Check the lock cylinder and sensor.
w Press the RESET switch.
Refer to pages 29.
q Remove the belt loop which was set incorrectly.
w Press the RESET switch.
e
Press the LOOP switch and then set a new belt loop.
Press the RESET switch.
Press the RESET switch.
q
Turn the machine pulley to check that it is not locked.
w Press the RESET switch.
Press the RESET switch and then reset the scale.
Press the RESET switch and then reset the scale.
Check the operation at the X or Y home position.
Turn off the power and check the operation of the
fan inside the box.
q Turn off power switch.
w Wait 10 seconds or more, and then turn the
power back on again.
Error code Problem
Solution
