Brother MFC-7365DN Service Manual

3-5
Confidential
*1
The tightening torque differs between machines produced in China and machines produced
in Vietnam. Check the serial number label attached to the rear of the machine to confirm the
country your machine was produced.
Low voltage power supply PCB
ASSY
Screw pan (S/P washer)
M3.5x6
10.5±0.05 (5±0.5)
Taptite flat B M3x10 1
0.45 ± 0.05 (4.5 ± 0.5)
Taptite bind B M4x12 1 0.8±0.1 (8±1)
High voltage power supply PCB
ASSY
Taptite bind B M4x12 1 0.8±0.05 (8±0.5)
New toner sensor PCB ASSY Taptite bind B M3x10 1 0.5±0.05 (5±0.5)
Laser unit Taptite cup S M3x8 SR 4 0.8±0.05 (8±0.5)
Main PCB ASSY Taptite cup S M3x6 SR 3 0.6±0.1 (6±1)
Front chute ASSY Taptite bind B M4x12 2 0.8±0.1 (8±1)
Under bar Taptite bind B M4x12 1 0.8±0.1 (8±1)
Chute ground plate Taptite bind B M3x10 1
0.55 ± 0.05 (5.5 ± 0.5)
PF frame ASSY Taptite bind B M4x12 1 0.8±0.1 (8±1)
FG plate laser L Taptite cup S M3x6 SR 1 0.8±0.1 (8±1)
Main frame L ASSY
Taptite bind B M4x12 2 0.8±0.1 (8±1)
Taptite cup S M3x6 SR 2 0.8±0.1 (8±1)
Develop drive sub ASSY
Taptite cup S M3x6 SR 1 0.8±0.1 (8±1)
Taptite bind B M4x12 3 0.8±0.1 (8±1)
Motor drive sub ASSY Taptite bind B M4x12 6 0.8±0.1 (8±1)
Main motor Screw bind M3x4 3
0.65 ± 0.05 (6.5 ± 0.5)
Main PCB shield
Taptite cup S M3x6 SR 1 0.6±0.1 (6±1)
Taptite bind B M4x12 2 0.8±0.1 (8±1)
Location of screw Screw type Q’ty
Tightening torque
N · m (kgf · cm)

Brother MFC-7365DN Specifications

Printing Specifications

print technology	Electrophotographic Laser
print speed	Up to 24ppm
print resolution	Up to 1200 x 600 dpi

Copying Specifications

copy speed	Up to 24cpm
copy resolution	600 x 600 dpi
copy reduction/enlargement	25% - 400% in 1% increments

Scanning Specifications

scanner type	Color Flatbed with ADF
document glass size	8.5” x 11” (letter)
scan resolution	Optical: Up to 600 x 2400 dpi

Paper Handling

paper size maximum	Up to 8.5” x 14” (legal size)
paper input capacity maximum	250-sheet capacity paper tray, single-sheet manual feed slot
output capacity maximum	100 sheets (face down), 1 sheet (face up)

Weight and Dimensions

unit dimensions	15.9” W x 15.7” D x 12.4” H
unit weight	25.6 lbs.
carton weight	32.6 lbs.
carton dimensions	20.7” W x 20.1” D x 19.4” H
