Brother MFC-7365DN

2-4
Confidential
2. OVERVIEW
2.1 Cross-section Drawing
■ Printer part
Fig. 2-2
Eject roller 2 Eject Pinch Roller Exposure drum Develop roller Supply roller Laser unit
Manual paper
tray cover
Regist roller
Registration
front actuator
Registration
rear actuator
Paper edge
actuator
Paper tray
Separation
pad
Separation
roller
Pick-up
roller
DX feed rollerDX feed roller Duplex Tray Transfer roller PlateHalogen heaterPressure roller
Back cover
<Front side><Back side>
Eject actuator
Eject roller 1
Heat roller
