3-51
Confidential
9.10.7
Separation Roller ASSY
(1) Unlock the lock of the conductive bushing to remove the separation roller ASSY.
Fig. 3-35
Separation roller ASSY
Conductive bushing
Conductive bushing
1c
1a
1b
1b
