3-54
Confidential
9.10.10
Document Feed Roller ASSY
(1) Unlock the lock of the conductive bushing to remove the document feed roller ASSY.
Fig. 3-39
Document feed roller ASSY
Conductive bushing
Conductive bushing
1b
1b
1a
1c
