3-61
Confidential
9.11 Document Cover ASSY (For models without ADF)
(1) Release the hooks of the hinge L and the hinge R to remove the document cover ASSY.
Fig. 3-46
Document cover ASSY
Hinge R
Hinge L
Hook
Hook
Hook
Hook
