Brother MFC-7365DN

3-62
Confidential
(2) Remove the taptite cup B M3x10 screw, and remove the hinge L and the hinge L support
from the hinge arm.
(3) Remove the taptite cup B M3x10 screw, and remove the hinge R and the hinge R support
from the hinge arm.
Fig. 3-47
Document cover
Hinge R
Hinge R support
Taptite cup B M3x10
Taptite cup B M3x10
Hinge L support
Hinge L
