Brother MFC-7365DN

3-106
Confidential
9.35 Internal Temperature Sensor
(1) Remove the harness of the internal temperature sensor from the guide of the frame L
ASSY, and remove the internal temperature sensor.
Fig. 3-95
Harness routing: Refer to “3. Internal temperature sensor”.
Internal temperature sensor
Guide
