Brother MFC-7365DN

3-100
Confidential
9.32 Main Frame L ASSY
(1) Remove the two taptite bind B M4x12 screws to remove the front chute ASSY.
(2) Remove the paper edge sensor harness ASSY from the guides of the main frame L
ASSY.
Fig. 3-89
Taptite bind B M4x12
Guides
Guide
Front chute ASSY
Paper edge sensor
harness ASSY
(Only for the models with paper edge actuator)
