9.9 Side Cover R
(1) Remove the taptite bind B M4x12 screw.
(2) Release the hooks in the order of 1a, 1b and 1c, and remove the side cover R.
Fig. 3-25
Side cover R
Hooks
Hook
Hook
Hooks
Hooks
1b
1c
1a
Taptite bind B M4x12
