4-5 Confidential
1.5 Inputting the Adjusted Value of the Laser Unit
Fig. 4-1
Note:
• When replace the laser unit, make sure to attach the serial label which is provided with
the new laser unit to the laser plate.
• When input the adjusted value, make sure to refer to the laser serial label which is
provided with the new laser unit.
Laser plate
Laser unit
Laser serial label
To Next Page
