Brother MFC-7365DN

3-37
Confidential
(3) Remove the two eject pinch roller L ASSY and the two eject pinch roller R ASSY from
the inner chute ASSY.
(4) Remove the four exit pinch roller springs from the eject pinch roller L ASSY and the eject
pinch roller R ASSY.
Fig. 3-18
Eject pinch roller R ASSY
Eject pinch roller L ASSY
Exit pinch roller springs
Exit pinch roller springs
Inner chute ASSY
