3-65
Confidential
(4) Remove the pull arm L and the pull arm spring from the pull arm guide.
(5) Remove the pull arm R and the pull arm spring from the pull arm guide.
Fig. 3-50
Pull arm spring
Pull arm spring
Pull arm L
Pull arm R
Rib
Rib
Rib
Pull arm guide
Pull arm guide
