(3) Remove the two screw pan (S/P washer) M3.5x6 screws.
(4) Remove the NCU FG harness ASSY from the guide.
Fig. 3-61
Harness routing: Refer to “16. NCU FG harness ASSY”.
NCU FG harness ASSY
NCU FG harness ASSY
Screw pan (S/P washer ) M3.5x6
(right side)
Screw pan (S/P washer ) M3.5x6
(upper side)
Guide
