Brother MFC-7365DN Service Manual

5-10
Confidential
* For details of worker switch, refer to the separate manual.
<Operating Procedure>
(1) Press the 1 and 0 buttons in this order in the initial state of the maintenance mode.
In the case of the model without the numeric keys; Press the or button. The
“MAINTENANCE 10” appears on the LCD. Then press the OK button.
The machine displays “WSW00” on the LCD and becomes ready to accept a worker
switch number.
(2) Enter the desired number from the worker switch numbers (01 through 78). The
following appears on the LCD. In the case of the model without the numeric keys; Press
the or button. Select the desired worker switch number.
(3) Enter a value to be set (0 or 1) using the 0 and 1 buttons. In the case of the model
without the numeric keys; If press the button, it is changed to “1”. And press the
button, it is changed to “0”. Select the value by this method.
(4) Press the OK button. This operation saves the newly entered selector values onto the
EEPROM and readies the machine for accepting a worker switch number.
(5) Repeat steps (2) through (4) until the modification for the desired worker switches is
completed.
(6) When the Stop/Exit button is pressed, the machine beeps for one second and returns to
the initial state of the maintenance mode.
WSW71 Reserved (Change of the setting is prohibited)
WSW72 Reserved (Change of the setting is prohibited)
WSW73 Reserved (Change of the setting is prohibited)
WSW74 ADF stop control
WSW75
Paper feeding parameter for turning the document counter when the
machine takes action duplex scanning
WSW76
The limited number of the documents in reverse for paper ejection of the
simplex scanning from ADF
WSW77
The limited number of the documents in reverse for paper ejection of the
duplex scanning from ADF
WSW78 Recording stop function when the drum reaches the end of life
Note:
• To cancel this operation and return to the machine to the initial state of the maintenance
mode during the above procedure, press the Stop/Exit button.
• If there is a pause of more than one minute after a single-digit number is entered for
double-digit worker switch numbers, the machine will automatically return to the initial
state of the maintenance mode.
WSW No. Function
WSWXX = 0 0 0 0 0 0 0 0
Selector 1 Selector 8

Brother MFC-7365DN Specifications

Printing Specifications

print technology	Electrophotographic Laser
print speed	Up to 24ppm
print resolution	Up to 1200 x 600 dpi

Copying Specifications

copy speed	Up to 24cpm
copy resolution	600 x 600 dpi
copy reduction/enlargement	25% - 400% in 1% increments

Scanning Specifications

scanner type	Color Flatbed with ADF
document glass size	8.5” x 11” (letter)
scan resolution	Optical: Up to 600 x 2400 dpi

Paper Handling

paper size maximum	Up to 8.5” x 14” (legal size)
paper input capacity maximum	250-sheet capacity paper tray, single-sheet manual feed slot
output capacity maximum	100 sheets (face down), 1 sheet (face up)

Weight and Dimensions

unit dimensions	15.9” W x 15.7” D x 12.4” H
unit weight	25.6 lbs.
carton weight	32.6 lbs.
carton dimensions	20.7” W x 20.1” D x 19.4” H
