Brother MFC-7365DN Service Manual

5-20
Confidential
Page Protection Configure the setting to protect the page memory, when recording in
computer. Set in the PCL-Core. There is not the influence of the memory
management problem of the MFC.
Emulation Configure the setting for the Emulation. Change the setting of the
Function Menu. When the data include the ENTER LANGUAGE, the
setting becomes effective. And this setting is ignored.
Auto I/F Time Configure the setting for the interface open time. The function is in the
PC-Print. When the PC-Scan/Remote-SetUp works on the way, the
setting becomes invalid.
Media Type Effective for the print from the computer. When set the type of the
recording paper on the computer, the setting becomes effective. And this
setting is ignored. The default value is different by the country setting.
China is the Thin, and others are the Plain.
Paper Size Switching of the area of develop the image. Does not set the Paper Size
of the Menu, set the drawing size of the PC-Print. When set the size of
the recording paper on the computer, the setting becomes effective. And
this setting is ignored. The default value is different by the country
setting. U.S.A/Canada are the Letter, and others are the A4.
Copies Effective for the print from the computer. When set the number of the
copies on the computer, the setting becomes effective. And this setting
is ignored.
Orientation Configure the switching for the print direction. Effective for the print from
the computer.
P-Pos X-Offset Configure the setting for the offset print position of the landscape
orientation. Effective for the print from the computer. When set the
X-Offset on the computer, the setting becomes effective. And this setting
is ignored.
P-Pos Y-Offset Configure the setting for the offset print position of the portrait
orientation. Effective for the print from the computer. When set the
Y-Offset on the computer, the setting becomes effective. And this setting
is ignored.
AutoFF Configure the setting for the ON/OFF of the Auto Form Feed. Effective
for the print from the computer.
AutoFF Time Configure the setting for the Time Out, when the Auto Form Feed is ON.
FF Surpress Configure the setting for the skip of the blank page. Effective for the print
from the computer. The blank data in the Copy/Fax cannot be turned
ON/OFF in this setting.
Auto LF Configure the setting for the auto line feed.
Auto CR Configure the setting for the auto Carriage Return.
Auto WRAP Configure the setting for the auto CRLF at the print width.
Auto Skip Configure the setting for the skip at the back-end/tip of the recording
paper and add the blank space.
Left Margin Configure the setting for the column space at the left end.
Right Margin Configure the setting for the column space at the right end.
Top Margin Configure the setting for the space at the upper end.
Bottom Margin Configure the setting for the space at the bottom end.
Lines Configure the setting for the number of the lines in the PCL.
Error Print Configure the setting for the Error Print of the BR-Script 3.
LCD Detail description

Brother MFC-7365DN Specifications

Printing Specifications

print technology	Electrophotographic Laser
print speed	Up to 24ppm
print resolution	Up to 1200 x 600 dpi

Copying Specifications

copy speed	Up to 24cpm
copy resolution	600 x 600 dpi
copy reduction/enlargement	25% - 400% in 1% increments

Scanning Specifications

scanner type	Color Flatbed with ADF
document glass size	8.5” x 11” (letter)
scan resolution	Optical: Up to 600 x 2400 dpi

Paper Handling

paper size maximum	Up to 8.5” x 14” (legal size)
paper input capacity maximum	250-sheet capacity paper tray, single-sheet manual feed slot
output capacity maximum	100 sheets (face down), 1 sheet (face up)

Weight and Dimensions

unit dimensions	15.9” W x 15.7” D x 12.4” H
unit weight	25.6 lbs.
carton weight	32.6 lbs.
carton dimensions	20.7” W x 20.1” D x 19.4” H
