Brother MFC-7365DN Service Manual

5-34
Confidential
LCD Description
Picked-up pages
by paper size
A4+LTR: Number of A4/Letter size sheets picked up
LG+F0L: Number of Legal/Folio size sheets picked
up
B5+EXE: Number of B5/Executive size sheets picked
up
ENVLOP: Number of envelopes picked up
A5: Number of A5 size (including A5R) sheets
picked up
OTHER: Number of other-size (including JIS B6)
sheets picked up
Print pages by pa-
per types *
4
PLTNRE: Printed pages of plain, thin, and recycled
paper
TKTRBD: Printed pages of thick, thicker, and bond pa-
per
ENVTYP: Printed pages of envelope, envelope thick,
and envelope thin
HAGAKI: Printed pages of Hagaki
LABEL: Printed pages of label
Number of
scanned pages
ADSX_PG Number of pages scanned in singled sided
scanning with ADF.
FB_PG Number of pages scanned with document
table
Developing bias re-
lated time
KDEV_BIAS: Black developing bias voltage (unit:V)
Power distribution
time
POWER: Power distribution time (unit: H)
PWRCNT: Number of times that the power is turned
ON
Jam related items TTL_JAM Total number of times when a jam occurs
TR1_JAM Number of times when a jam occurs at the
paper tray1
MN_JAM Number of times when a jam occurs at the
manual tray
DX_JAM Number of sheets jammed in the DX
IN_JAM Number of sheets jammed in the product
RE_JAM Number of sheets jammed around the back
cover
ADSX_JAM Number of jams that occurred at singled sid-
ed scanning with ADF.

Brother MFC-7365DN Specifications

Printing Specifications

print technology	Electrophotographic Laser
print speed	Up to 24ppm
print resolution	Up to 1200 x 600 dpi

Copying Specifications

copy speed	Up to 24cpm
copy resolution	600 x 600 dpi
copy reduction/enlargement	25% - 400% in 1% increments

Scanning Specifications

scanner type	Color Flatbed with ADF
document glass size	8.5” x 11” (letter)
scan resolution	Optical: Up to 600 x 2400 dpi

Paper Handling

paper size maximum	Up to 8.5” x 14” (legal size)
paper input capacity maximum	250-sheet capacity paper tray, single-sheet manual feed slot
output capacity maximum	100 sheets (face down), 1 sheet (face up)

Weight and Dimensions

unit dimensions	15.9” W x 15.7” D x 12.4” H
unit weight	25.6 lbs.
carton weight	32.6 lbs.
carton dimensions	20.7” W x 20.1” D x 19.4” H
