Brother MFC-7365DN Service Manual

2-34
Confidential
■ Error code 44
The toner cartridge is not installed.
■ Error code 45
These errors do not usually occur in the normal use. The conceivable causes are noise around
the installation site, fluctuation of the power supply voltage, and failures in the software.
Error, which cannot be specified, occurs.
Error code 46
Error, which cannot be specified, occurs.
Error code 47
Error, which cannot be specified, occurs.
Error code 48
Error, which cannot be specified, occurs.
Error code 49
Error, which cannot be specified, occurs.
No Toner
Open the Front Cover, then install the Toner Cartridge.
<User Check>
• Install the toner cartridge.
Step Cause Remedy
1
Dirt on the electrode of the drum
unit and on the machine
Clean the dirt on the contact points of the
both electrodes.
(Refer to Fig. 2-11, Fig. 2-12)
2
Harness connection failure of high
voltage power supply PCB
Check the harness connection of the high
voltage power supply PCB and reconnect
it.
3
High voltage power supply PCB
failure
Replace the high voltage power supply
PCB ASSY.
4 Main PCB failure Replace the main PCB ASSY.
No Toner
Open the Front Cover, then install the Toner Cartridge.
No Toner
Open the Front Cover, then install the Toner Cartridge.
No Toner
Open the Front Cover, then install the Toner Cartridge.
Replace Drum
Replace Drum

Brother MFC-7365DN Specifications

Printing Specifications

print technology	Electrophotographic Laser
print speed	Up to 24ppm
print resolution	Up to 1200 x 600 dpi

Copying Specifications

copy speed	Up to 24cpm
copy resolution	600 x 600 dpi
copy reduction/enlargement	25% - 400% in 1% increments

Scanning Specifications

scanner type	Color Flatbed with ADF
document glass size	8.5” x 11” (letter)
scan resolution	Optical: Up to 600 x 2400 dpi

Paper Handling

paper size maximum	Up to 8.5” x 14” (legal size)
paper input capacity maximum	250-sheet capacity paper tray, single-sheet manual feed slot
output capacity maximum	100 sheets (face down), 1 sheet (face up)

Weight and Dimensions

unit dimensions	15.9” W x 15.7” D x 12.4” H
unit weight	25.6 lbs.
carton weight	32.6 lbs.
carton dimensions	20.7” W x 20.1” D x 19.4” H
