Brother MFC-7365DN Service Manual

2-60
Confidential
■ Error code B1
Dark level offset data level error for scanning.
* This error is indicated on the LCD in the maintenance mode.
Error code B2
Dark level offset data level error for scanning.
* This error is indicated on the LCD in the maintenance mode.
Error code B3
The scanning area setting left edge detection error. (white tape)
* This error is indicated on the LCD in the maintenance mode.
Error code B4
The scanning area setting right edge detection error. (white tape)
* This error is indicated on the LCD in the maintenance mode.
■ Error code B5, B6
These errors do not usually occur in the normal use. The conceivable causes are noise around
the installation site, fluctuation of the power supply voltage, and failures in the software.
Error, which cannot be specified, occurs.
Scanner Error B1
Scanner Error B2
Scanner Error B3
Scanner Error B4
Step Cause Remedy
1 CIS unit failure Replace the CIS unit.
2 Document scanner unit failure Replace the document scanner unit.
3 Main PCB failure Replace the main PCB ASSY.
---
<User Check>
• Turn OFF the power switch, and turn it ON again after a while.
Step Cause Remedy
1 Main PCB failure Replace the main PCB ASSY.

Brother MFC-7365DN Specifications

Printing Specifications

print technology	Electrophotographic Laser
print speed	Up to 24ppm
print resolution	Up to 1200 x 600 dpi

Copying Specifications

copy speed	Up to 24cpm
copy resolution	600 x 600 dpi
copy reduction/enlargement	25% - 400% in 1% increments

Scanning Specifications

scanner type	Color Flatbed with ADF
document glass size	8.5” x 11” (letter)
scan resolution	Optical: Up to 600 x 2400 dpi

Paper Handling

paper size maximum	Up to 8.5” x 14” (legal size)
paper input capacity maximum	250-sheet capacity paper tray, single-sheet manual feed slot
output capacity maximum	100 sheets (face down), 1 sheet (face up)

Weight and Dimensions

unit dimensions	15.9” W x 15.7” D x 12.4” H
unit weight	25.6 lbs.
carton weight	32.6 lbs.
carton dimensions	20.7” W x 20.1” D x 19.4” H
