3-7
Confidential
■ Leveler roller ASSY
Paper pull-in roller
(3_006)
Lubricate these 2 points
Leveler roller ASSY
(3_008)
Engine unit
Paper pull-in roller
Rib
Lubricate here
Paper pull-in gear
Paper pull-in roller
