Brother MFC-J285DW Service Manual

2-43
Confidential
■ Error Code 8A
The PF encoder sensor cannot detect the rotation of the paper feed motor.
Error Code 8C
Overcurrent protection was activated in the driver IC during paper feed motor operation.
Error Code 8F
Paper feed motor does not stop.
The PF encoder sensor cannot detect the rotation of the paper feed motor.
<User Check>
- Remove the jammed recording paper in jam clear cover part, platen part and front part.
Disc Jam / Paper Jam
LCD
Disc Jam / Paper Jam
LCD
Unable to print 8F
LCD
Step Cause Solution
1 Foreign materials in the recording
paper feeding path
Remove foreign materials.
2 Paper feed motor harness
connection failure
Reconnect the paper feed motor harness.
3 PF encoder sensor harness
connection defective
Reconnect the PF encoder sensor harness.
4 PF encoder disk defective Replace the PF encoder disk.
5 PF encoder sensor defective Replace the PF encoder sensor PCB ASSY.
6 Paper feed motor defective Replace the engine unit.
7 Main PCB defective Replace the main PCB ASSY.
