Brother MFC-J285DW Service Manual

4-1
Confidential
CHAPTER 4 ADJUSTMENTS AND UPDATING OF SETTINGS,
REQUIRED AFTER PARTS REPLACEMENT
1 IF YOU REPLACE THE MAIN PCB ASSY
<Operations>
1.1 Customize Destinations (Maintenance mode 74)
1.2 Automatically Set the CIS Type (Maintenance mode 59)
1.3 Install the Firmware (Maintenance mode 28)
1.4 EEPROM Parameter Initialization (Maintenance mode 01)
1.5 Restore Head Calibration Data (Maintenance mode 68)
1.6 Set the Serial Number (Maintenance mode 80)
1.7 Update the head property data (Maintenance mode 68)
1.8 Restore machine information (Maintenance mode 46)
1.9 Adjust the Touch Panel (Maintenance mode 78)
1.10 Acquire Black and White Level Data (Maintenance mode 55)
1.11 Adjustment of Ruled Lines (Maintenance mode 65)
1.12 Update the Paper Feeding Correction Values (Maintenance mode 58)
1.13 Margin Adjustment in Borderless Printing (Maintenance Mode 66)
1.14 Reset Purge and Flushing Counts (Maintenance mode 80)
1.15 Creating of Head Calibration Data and Writing it into Flash ROM (Maintenance mode 02)
1.16 Check Scanning and Printing
<Requirements>
(1) USB flash memory or SD card: 1 piece
(2) USB cable: 1 piece
(3) Create a temporary folder in the PC's C drive (Windows
®
XP or later).
(4) Service setting tool (brusbsn.zip)
Make a copy of the Service setting tool in the temporary folder in the C drive. Decompress the
file and execute "brusbn.exe" by double-clicking on it.
(5) Download utility (FILEDG32.EXE)
Make a copy of the download utility in the temporary folder in the C drive.
(6) Maintenance driver (MaintenanceDriver.zip)
Make a copy of the maintenance driver in the temporary folder in the C drive. Extract the
copied file and install it. Refer to "APPENDIX 3. INSTALLING THE MAINTENANCE
PRINTER DRIVER" for details on the installation.
(7) Firmware
LZXXXX_$.pjl (For installing firmware using a PC with external memory)
LZXXXX_$.upd (For installing firmware using a PC)
(8) Data files of print patterns
(9) Stylus for touch panel

Brother MFC-J285DW Specifications

General

Print technology	Inkjet
Maximum resolution	6000 x 1200 DPI
Economical printing	Yes
Print speed (ISO/IEC 24734) mono	12 ipm
Print speed (ISO/IEC 24734) color	10 ipm
Print speed (black, normal quality, A4/US Letter)	33 ppm
Print speed (color, normal quality, A4/US Letter)	27 ppm
Copier resize	25 - 400 %
Maximum copy resolution	- DPI
N-in-1 copy function (N=)	2, 4
Scan to	E-mail, File, Image, OCR
Scanner type	Flatbed scanner
Image formats supported	BMP, JPG, PCX, PNG, TIF
Maximum scan resolution	19200 x 19200 DPI
Document formats supported	HTM, PDF
Optical scanning resolution	1200 x 2400 DPI
Faxing	Color faxing
Fax memory	170 pages
Modem speed	14.4 Kbit/s
Fax transmission speed	7 sec/page
Digital sender	-
Maximum duty cycle	2500 pages per month
Number of print cartridges	4
Total input capacity	100 sheets
Total output capacity	50 sheets
Maximum print size	216 x 356 mm
Paper tray media types	Glossy paper, Photo paper, Transparencies
ISO A-series sizes (A0...A9)	A4
Photo paper sizes (imperial)	4x6, 5x7, 5x8 \
Paper tray media weight (imperial)	4 - 6 lbs
Display	LCD
Control type	Touch
Product color	Black
Display diagonal	1.8 \
Market positioning	Home & office
Ethernet LAN	No
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Security algorithms	SSID, WEP, WPA-PSK, WPA2-PSK
Online services supported	Box, Dropbox, Evernote, Facebook, Flickr, Google Drive, Picasa, Sky Drive
Mobile printing technologies	Apple AirPrint, Brother iPrint & Scan, Google Cloud Print
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Sound pressure level (copying)	50 dB
AC input voltage	100 - 120 V
AC input frequency	50 - 60 Hz
Power consumption (average operating)	- W
Sustainability certificates	ENERGY STAR
Package depth	457 mm
Package width	477 mm
Package height	228 mm
Package weight	9380 g
Storage temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	373 mm
Width	409 mm
Height	160 mm
