2-28
Confidential
■ Error Code 32
Head capping cannot be done.
<User Check>
- Remove the jammed recording paper from the platen part and the maintenance unit part.
■ Error Code 35
Abnormal stopping of the head/carriage unit
Caused by factors other than recording paper jams such as encoder stains when ink is not
discharging.
<User Check>
- Remove the jammed recording paper from the engine part.
Unable to print 32
LCD
Step Cause Solution
1 Foreign materials around the
maintenance unit
Remove foreign materials.
2 Switching lever guide out of place Reattach the switching lever guide.
(Refer to page 2-27)
3 Leveler roller ASSY not properly
attached to the head/carriage unit
Reattach the leveler roller ASSY to the head/
carriage unit.
4 Leveler roller ASSY defective Replace the leveler roller ASSY.
5 Maintenance unit defective Replace the maintenance unit.
6 Main PCB defective Replace the main PCB ASSY.
Unable to print 35
LCD
Step Cause Solution
1 CR encoder strip stained Clean the CR encoder strip.
2 CR encoder strip out of place Reattach the CR encoder strip.
3 Leveler roller ASSY not properly
attached to the head/carriage unit
Reattach the leveler roller ASSY to the head/
carriage unit.
4 CR encoder strip defective Replace the CR encoder strip.
5 CR encoder sensor defective Replace the carriage PCB ASSY.
6 Leveler roller ASSY defective Replace the leveler roller ASSY.
7 Main PCB defective Replace the main PCB ASSY.
To Next Page
