5-27
Confidential
1.3.13 Backup of Machine Information (Maintenance mode 46)
<Function>
This procedure backs up the machine information and user setting information into an external
memory (memory card or USB flash memory) and restores it when necessary.
- Machine information (Preset values, count values, error information, machine specifications
data, etc.)
- User setting information (telephone directory, password, station ID, transfer information,
telephone area code, user settings, etc.)
- Other data (Received fax data, ICM/OGM data, etc.)
Note that the following information cannot be backed up.
- Serial number of the machine
- MAC address
- Call and caller ID records
- Activity report
- Fax data to be sent (by delayed-timer, redialing, and polling)
- Head calibration data
Note • The user can use the backup and restoration (given on the next page) procedures. However,
this restoration procedure can be done only with the "Import from Card" function; it is not
available with the "Import all" function.
• An external memory (memory card or USB flash memory) for backup should have a free
space larger than the RAM size of the machine.
• When performing this procedure for any other machine with the same external memory,
delete the data previously stored in the external memory.
• Do not use a memory stick; using it may fail to transfer data correctly.
<Operating Procedure>
Backup procedure
(1) On the PC, create a "BROTHER" folder in an external memory to be used for saving backup
data.
(2) Insert the external memory in (1) into the slot of the machine in the initial stage of the
maintenance mode.
The machine displays "**** Active" on the LCD. ("****" shows the name of the external
memory inserted.)
Note • Do not insert more than one external memory at a time.
• If the external memory inserted already contains backup data of the same model, the
existing data will be overwritten with new data.
(3) Press the [4] and [6] keys in this order.
The machine displays "Export to Card" on the LCD.
(4) Press the [Mono Start] key.
The file name "********.msd" appears on the LCD. The "********" is unique to each model.
(5) Press the [Mono Start] key.
The machine redisplays "Export to Card" on the LCD.
To Next Page
